Effective aerial surveying needs to see the invisible. That’s why Mavic 3 Multispectral has two forms of sight. It combines an RGB camera with a multispectral camera to scan and analyze crop growth with total clarity. Agricultural production management requires precision and data, and the Mavic 3M delivers both.
Compact and portable
Foldable for easy storage
Safe and stable
Omnidirectional Obstacle Avoidance [1]
15km Transmission Distance [2]
Multispectral Camera
4 × 5MP
G/R/RE/NIR
Precise positioning
Centimeter-level RTK positioning
Microsecond-level time synchronization
RGB Camera
20 MP
4/3 CMOS, mechanical shutter
Efficient aerial surveying
Up to 200 hectares per flight [3]
Multispectral + RGB imaging system
Highly integrated imaging system
Newly upgraded system with one 20MP RGB camera and four 5MP multispectral cameras (green, red, red edge, and near-infrared). Enables applications such as high-precision aerial surveying, crop growth monitoring, and natural resource surveys.
5MP Multispectral Camera
Near-infrared (NIR)
860 nm ± 26 nm
Red edge (RE)
730 nm ± 16 nm
Red (R)
650 nm ± 16 nm
Green (G)
560 nm ± 16 nm
RGB Camera Characteristics
4/3 CMOS
20MP image sensor
1/2000s
Fastest mechanical shutter speed
0.7s
High-speed burst when RGB camera is used
Sunlight Sensor
The built-in sunlight sensor captures solar irradiance and records it in an image file, allowing for light compensation of image data during 2D reconstruction. This results in more accurate NDVI results, as well as improved accuracy and consistency of data acquired over time.
RTK module
Accurate images that capture every pixel
Mavic 3M with RTK module for centimeter-level positioning. Flight control, the camera, and the RTK module sync in microseconds to accurately capture the location of each camera’s imaging center. This enables Mavic 3M to do high-precision aerial surveying without using ground control points.
Stable signal, smooth image transmission
The O3 transmission integrates two transmitting signals and four receiving signals to support 15km ultra-long transmission distances.
RTK module
Omnidirectional obstacle sensing, terrain-follow aerial surveying
The aircraft features multiple wide-FOV vision sensors that accurately detect obstacles in all directions for omnidirectional obstacle avoidance. The terrain-follow aerial surveying can be easily performed in steep-slope landscapes.
Efficient and reliable battery life
Ultra-long battery life, fast bursts
43 Minute Cruise Time
200 Hectare Coverage
A single flight can complete mapping operations over an area of 200 hectares.
100W Battery Charging Hub High-Efficiency Fast Charging
88W Fast Charging Aircraft
DJI Mavic 3M Applications
Mavic 3M allows terrain-follow aerial surveying of orchards, even on sloped landscapes. Together with DJI Terra or DJI SmartFarm Platform [6] to reconstruct high-resolution orchard maps, automatically identify the number of trees, distinguish trees from other obstacles or objects, and generate three-dimensional operation routes for agricultural drones, making operations safer and more efficient.
- Mavic 3M aerial surveying
- DJI Terra/DJI SmartFram Platform [6] Mapping
- Generate 3D Routes
- Agricultural Drone Operation
For rice fertilization, cotton growth regulation, and potato foliar fertilizer spraying, the Mavic 3M is used to obtain multi-spectral images of crops. DJI Terra or the DJI SmartFarm Platform [6] can then generate NDVI and other vegetation indices maps, capturing differences in crop potential and generating prescription maps that allow agricultural drones to execute variable-rate application. This ultimately allows users to reduce costs, increase yield, and protect the environment.
- Mavic 3M aerial surveying
- DJI SmartFarm Platform
- Generates prescription maps for cropland
- Agricultural Drone
The Mavic 3M can carry out automatic field scouting. The field scout images can be uploaded to the DJI SmartFarm Platform [6] in real time through a 4G network. It can find abnormalities, such as emergence deficiencies, weed pressure, and crop lodging in a timely manner. It can also conduct intelligent analyses, such as cotton seedling identification and rice production testing, using AI identification for real-time sharing of crop growth information, guidance of agronomic activities, and easy management of 70 hectares of farmland by one person.
Environmental Monitoring and Natural Resources Survey
The Mavic 3M can also be used in environment and natural resource surveys, such as water enrichment monitoring, forest distribution surveys, urban green area surveys, and more.
Open Ecosystem
Cloud API
The Mavic 3M can be directly connected to a third-party cloud platform via Pilot 2's built-in DJI Cloud API based on the MQTT protocol. There is no need to develop an app separately to enable the transmission of UAV equipment information, live streaming, photo data, and other information.
MSDK
The Mavic 3M supports Mobile SDK 5 (MSDK5) with a fully open-source production code sample. The MSDK5 makes it possible to develop a proprietary control app for UAV field patrol, smart surveying, and other scenarios, making it more user-friendly.
